Dual ceramic ball bearing system provides optimal turbo response &better durability by reducing the shaft-motion 13 Blade PTG-Aero billet compressor wheel with extended tapered tip technology 9 Blade PTG-Aero Inconel 713c turbine wheel Anti-Surge ported-shroud compressor inlet, cover integrated with the speed sensor and pressure ports Water fittings included with super core 8 Options in Turbine Housing Compressor Wheel: 76.6*109.2mm Turbine Wheel: 89*81.6mm Compressor Inlet: 5″ Hose Compressor Outlet: 3″ V-Band Turbine Inlet: 3″ V-Band/T4 open/ T4 divided Turbine Outlet: 3.5″ V-Band Water Ports: -6AN Oil Feed: Flange Required(Recommended size: -4AN Std T4 Flange Restricted) Oil Drain: -12AN(O-Ring sealed Flange Kit Incl’) Comes with Inlet flange and clamp (DVB) and Outlet flange and clamp PLEASE ADVISE US AT CHECKOUT WITH WHAT FLANGE AND HOUSING SIZE YOU WOULD LIKE T4 1.01, T4 1.15, T4 1.28, T4 1.44 or DUAL VBAND 1.01, 1.15 or 1.28ALSO T51R MOD ADD $400

Read more less

Dual ceramic ball bearing system provides optimal turbo response &better durability by reducing the shaft-motion 9 Blade PTG-Aero billet compressor wheel with extended tapered tip technology 9 Blade PTG-Aero Inconel 713c turbine wheel Anti-Surge ported-shroud compressor inlet, cover integrated with the speed sensor port Compressor Wheel: 79*98mm Turbine Wheel: 82*75mm Compressor Inlet: 5″ Hose Compressor Outlet: 3″ V-Band Turbine Inlet: 3″ V-Band Turbine Outlet: 3.5″ V-Band Water Ports: -6AN Oil Feed: Flange Required(Recommended size: -4AN Std T4 Flange) Oil Drain: -12AN(O-Ring sealed Flange Kit Incl’) PLEASE ADVISE US AT CHECKOUT WITH WHAT FLANGE AND HOUSING SIZE YOU WOULD LIKE T4 1.01, T4 1.15, T4 1.28 or DUAL VBAND 1.01, 1.15 or 1.28ALSO T51R MOD ADD $400

Read more less

Dual ceramic ball bearing system provides optimal turbo response &better durability by reducing the shaft-motion 10 Blade G-Aero billet compressor wheel with extended tapered tip technology 9 Blade G-Aero Inconel 713c turbine wheel Anti-Surge ported-shroud compressor inlet, cover integrated with the speed sensor port 8 Options in Turbine Housing Installation Hardware: 3” flange kit for Comp. Outlet, T4 Gasket/3” flange kit for Turbo. Inlet, 3.5”/4” flange kit for Turbo. Outlet and oil Drain Fitting kit are included by default Oil Feed Fitting needs to be bought separately Compressor Wheel: 79*98mm Turbine Wheel: 82*75mm Compressor Inlet: 4″ Hose Compressor Outlet: 3″ hose Water Ports: -6AN Oil Feed: Flange Required Oil Drain: -12AN(O-Ring sealed Flange Kit Incl’) Comes with Inlet flange and clamp (DVB) and Outlet flange and clamp PLEASE ADVISE US AT CHECKOUT WITH WHAT FLANGE AND HOUSING SIZE YOU WOULD LIKE T4 .95, T4 1.01, T4 1.15, T4 1.28 or DUAL VBAND 1.01, 1.15 or 1.28ALSO T51R MOD ADD $400

Read more less

Dual ceramic ball bearing with steel cage provides optimal turbo response &better durability by reducing the shaft-motion 71mm inducer 10 Blade PTG-Aero billet compressor wheel with extended tapered tip technology 9 Blade PTG-Aero Inconel 713c turbine wheel Anti-Surge ported-shroud compressor inlet, cover integrated with the speed sensor and pressure ports Water fittings included with the super core 2 Options in Turbine Housing HP rated at 1150HP at the flywheel Suitable engine size: 2.0-6.0L Compressor Wheel: 71*88mm Turbine Wheel: 77*70mm Compressor Inlet: 4″ Hose Compressor Outlet: 2.5″ V-Band Turbine Inlet: T4 divided Turbine Outlet: 4″ V-Band Water Ports: -6AN Oil Feed: Flange Required(Recommended size: -4AN Std T4 Flange ) Oil Drain: -12AN(O-Ring sealed Flange Kit Incl’) 2 Options in Turbine Housing: T4(Divided) 0.95 A/R, 1.06 A/R Comes with Inlet flange and clamp (DVB) and Outlet flange and clamp   PLEASE ADVISE US AT CHECKOUT WITH WHAT FLANGE AND HOUSING SIZE YOU WOULD LIKE T4 .95, T4 1.06 or DUAL VBAND 1.06ALSO T51R MOD ADD $400

Read more less

Dual ceramic ball bearing system provides optimal turbo response &better durability by reducing the shaft-motion 10 Blade PTG-Aero billet compressor wheel with extended tapered tip technology 9 Blade PTG-Aero Inconel 713c turbine wheel Anti-Surge ported-shroud compressor inlet, cover integrated with the speed sensor port Compressor Wheel: 73*91mm Turbine Wheel: 82*75mm Compressor Inlet: 4″ Hose Compressor Outlet: 3″ hose Turbine Outlet: 3.5″ V-Band Water Ports: -6AN Oil Feed: Flange Required(Recommended size: -4AN Std T4 Flange Restricted) Oil Drain: -12AN(O-Ring sealed Flange Kit Incl’) Comes with Inlet flange and clamp (DVB) and Outlet flange and clamp PLEASE ADVISE US AT CHECKOUT WITH WHAT FLANGE AND HOUSING SIZE YOU WOULD LIKE T4 .95, T4 1.01, T4 1.15, T4 1.28 or DUAL VBAND 1.01 OR 1.15ALSO T51R MOD ADD $400

Read more less

Dual ceramic ball bearing system provides optimal turbo response & better durability by reducing the shaft-motion 9 Blade G-Aero billet compressor wheel with extended tapered tip technology 9 Blade G-Aero Inconel 713c turbine wheel Anti-Surge ported-shroud compressor inlet, cover integrated with the speed sensor port Description: Compressor Wheel: 68*84mm Turbine Wheel: 68*62mm Compressor Inlet: 4?? Hose Compressor Outlet: 2.5?? V-Band Turbine Inlet: T3/T4 Turbine Outlet: 3?? V-Band Water Ports: 2-M14 x 1.5 Oil Feed: 7/16-24 UNF with a -4AN Restrictor Pre-installed Oil Drain: Std T3   PLEASE ADVISE US AT CHECKOUT WITH WHAT FLANGE AND HOUSING SIZE YOU WOULD LIKE T4 .82, T4 0.85, DUAL VBAND 0.83 OR 1.01ALSO T51R MOD ADD $400

Read more less

Dual ceramic ball bearing system provides optimal turbo response &better durability by reducing the shaft-motion 10 Blade G-Aero billet compressor wheel with extended tapered tip technology 9 Blade G-Aero Inconel 713c turbine wheel Anti-Surge ported-shroud compressor inlet, cover integrated with the speed sensor port 8 Options in Turbine Housing Installation Hardware: 3” flange kit for Comp. Outlet, T4 Gasket/3” flange kit for Turb. Inlet, 3.5”/4” flange kit for Turb. Outlet and oil Drain Fitting kit are included by default Oil Feed Fitting needs to be bought separately Compressor Wheel: 73*91mm Turbine Wheel: 82*75mm Compressor Inlet: 4″ Hose Compressor Outlet: 3″ hose Turbine Inlet: 3″ V-Band, T4 divided or T4 open Turbine Outlet: 3.5″ V-Band or 4″ V-Band Water Ports: -6AN Oil Feed: Flange Required(Recommended size: -4AN Std T4 Flange) Oil Drain: -12AN(O-Ring sealed Flange Kit Incl’) Comes with Inlet flange and clamp (DVB) and Outlet flange and clamp   PLEASE ADVISE US AT CHECKOUT WITH WHAT FLANGE AND HOUSING SIZE YOU WOULD LIKE T4 .95, T4 1.01, T4 1.15, T4 1.28 or DUAL VBAND 1.01, 1.15 or 1.28ALSO T51R MOD ADD $400

Read more less
