- Dual ceramic ball bearing system provides optimal turbo response &
better durability by reducing the shaft-motion
- 10 Blade G-Aero billet compressor wheel with extended tapered tip technology
- 9 Blade G-Aero Inconel 713c turbine wheel
- Anti-Surge ported-shroud compressor inlet, cover integrated with the speed sensor port
- 8 Options in Turbine Housing
- Installation Hardware: 3” flange kit for Comp. Outlet, T4 Gasket/3” flange kit for Turb. Inlet, 3.5”/4” flange kit for Turb. Outlet and oil Drain Fitting kit are included by default
- Oil Feed Fitting needs to be bought separately
-
- Compressor Wheel: 73*91mm
- Turbine Wheel: 82*75mm
- Compressor Inlet: 4″ Hose
- Compressor Outlet: 3″ hose
- Turbine Inlet: 3″ V-Band, T4 divided or T4 open
- Turbine Outlet: 3.5″ V-Band or 4″ V-Band
- Water Ports: -6AN
- Oil Feed: Flange Required(Recommended size: -4AN Std T4 Flange)
- Oil Drain: -12AN(O-Ring sealed Flange Kit Incl’)
- Comes with Inlet flange and clamp (DVB) and Outlet flange and clamp
PLEASE ADVISE US AT CHECKOUT WITH WHAT FLANGE AND HOUSING SIZE YOU WOULD LIKE T4 .95, T4 1.01, T4 1.15, T4 1.28 or DUAL VBAND 1.01, 1.15 or 1.28
ALSO T51R MOD ADD $400
