- Dual ceramic ball bearing system provides optimal turbo response &
better durability by reducing the shaft-motion
- 13 Blade PTG-Aero billet compressor wheel with extended tapered tip technology
- 9 Blade PTG-Aero Inconel 713c turbine wheel
- Anti-Surge ported-shroud compressor inlet, cover integrated with the speed sensor and pressure ports
- Water fittings included with super core
- 8 Options in Turbine Housing
- Compressor Wheel: 76.6*109.2mm
- Turbine Wheel: 89*81.6mm
- Compressor Inlet: 5″ Hose
- Compressor Outlet: 3″ V-Band
- Turbine Inlet: 3″ V-Band/T4 open/ T4 divided
- Turbine Outlet: 3.5″ V-Band
- Water Ports: -6AN
- Oil Feed: Flange Required(Recommended size: -4AN Std T4 Flange Restricted)
- Oil Drain: -12AN(O-Ring sealed Flange Kit Incl’)
- Comes with Inlet flange and clamp (DVB) and Outlet flange and clamp
PLEASE ADVISE US AT CHECKOUT WITH WHAT FLANGE AND HOUSING SIZE YOU WOULD LIKE T4 1.01, T4 1.15, T4 1.28, T4 1.44 or DUAL VBAND 1.01, 1.15 or 1.28
ALSO T51R MOD ADD $400
